Raymarine Axiom XL 16 Reman MFD Navionics, GA150 and RCR1

$5,523.00 $4,970.70 (Available - Call for Info 877-999-3699)
SALE!
Raymarine
Reviews (0)

Raymarine Axiom XL 16 Reman MFD Navionics, GA150 and RCR1

$5,523.00 $4,970.70 (Available - Call for Info 877-999-3699)

Raymarine Axiom XL 16 MFD Only Remanufactured with Navionics, GA150 and RCR1

Model: E70399RNAVBNDL

The Axiom XL range is the pinnacle of Raymarine navigation and modern helm integration.

Designed for glass bridge installations, Axiom XL displays offer superior... Read More...

SKU: #358421632861771 | Model: #E70399RNAVBNDL

Share:

Description Returns

Raymarine Axiom XL 16 MFD Only Remanufactured with Navionics, GA150 and RCR1

Model: E70399RNAVBNDL

The Axiom XL range is the pinnacle of Raymarine navigation and modern helm integration.

Designed for glass bridge installations, Axiom XL displays offer superior performance, large format visibility and elegant simplicity. Engineered to perform in extreme conditions, the fully waterproof Axiom XL family of glass bridge MFDS can be installed in both open cockpits and enclosed bridge stations. Each model uses in-plane switching technology (IPS) and Raymarine optical bonding to deliver wider viewing angles, sharp contrast, and unmatched readability in bright sun.

Axiom XL’s edge-to-edge glass construction gives vessel designers the ability to create integrated and elegant navigation helm appearance.

Specifications
General Specifications
Display Size15.6"
Display TypeIPS (In-Plane Switching)
Color Depth24 bit
Display Resolution1920 x 1080 FHD
Display Aspect Ratio16:9
Viewing AngleTop 88’ / Bottom 88’ / Left 88’ / Right 88’
Power
Nominal supply voltage12 / 24 Vdc
Operating voltage range8 Vdc to 32 Vdc
Fuse RequirementsInline fuse = 15Amp, or Thermal breaker = 15Amp
Max. Power60W
Environmental
Operating Temperature Range-25°C to + 55°C
Storage temperature range-30°C to +70°C
HumidityUp to 93% @40°C
Water Ingress ProtectionIPx6 and IPx7
Physical
Overall Dimensions W x D x H (mm)395 x 78 x 249
Product Weight (Kg)5.9
Other Specifications64 GB Solid State (62 GB usable)
Internal Storage

What's in the Box:
  • Axiom XL MFD
  • Suncover (Silicone)
  • Rear mounting bar x2
  • Documentation pack
  • Mounting gasket tape
  • Power / Video / NMEA 0183 cable. 1.5m (4.92ft) right-angled
  • Mounting bar fixings x4 (M5 x20)
  • Mounting fixings x4 (Including M5 bolts x35, M5 wavy washers, M5 nuts and mounting feet)
  • SeaTalkng to DeviceNet 1m (3.3ft) adapter cable
  • M3 screw x5, M3 spring washer and M3 crimp terminal (for optional grounding connection)
  • RayNet 2m (6.6ft) network cable
  • GA150 Antenna
  • RCR1 Card Reader
  • Navionics Navplus

  • SKU: #358421632861771
  • Weight: 20.00 lbs
  • Brand: Raymarine
  • Model: E70399RNAVBNDL
  • Shipping Dimensions: 0.00" x 0.00" x 0.00"
